Local CI/CD with Jenkins, Docker, and JCasC

May 21, 2023

Garaunteed to work in Windows WSL2, and probably in Linux and MacOS

Jenkins In Docker

This is part 1 of a series “Local CI/CD With Jenkins in Docker”:

The stack we build in the series can be used as the base stack for Mannings Live Project: CI/CD Pipeline for a Web Application Using Jenkins.

Steps:

  • build a custom Jenkins docker image with JCasC and Plugin Manager
  • run and test it for basic function
  • auto add credentials to talk to GitHub with JCasC
  • test the credentials with a simple pipeline to a private GitHub repo
  • develop shell scripts to manage the stack

Why Jenkins in Docker?

When I do local development I use my strongest machine, which is also my Windows gaming rig. I only use Windows for gaming so I don’t want the dev resources loading in Windows unless I need them. WSL (Windows Subsystem for Linux) works great for that. By default, the WSL Ubuntu “VM” does not load until I tell it to. On top of that, I configure my local dev stack to run in Docker and to only load when I tell them to.

Putting Jenkins in Docker also avoids getting tangled up in Java VM version hell on your dev machine. If you install Jenkins from the ground up, you also have to install Java. Jenkins container images already have the correct version of Java installed for the Jenkins version in the image. If another app in your stack requires a different Java VM, it doesn’t matter a bit.

However, running Jenkins as a Docker container using Docker daemon is problematic if you want to use Docker containers in your pipelines. Jenkins recommends using a DinD (Docker in Docker) container. This is suboptimal for production, but will work for a local dev stack.

If you have a dedicated VM for Jenkins, where you are not worried about java VM version differences, etc, then you should consider installing Jenkins in standalone mode, with Docker CLI installed on the same VM. That simplifies using Docker in your pipelines and better emulates production. The instructions below are still somewhat useful because they lay out how to user JCasC and plugins, in preparation of automating Jenkins setup.

We build this stack step-by-step to increase learning. If this were for efficiency, we’d use Docker Compose and some IaC tools like Ansible. A blog entry for that is on my TODO list.

Required Apps

Git CLI and a remote SCM

I installed generic git on Ubuntu in WSL2, so the daemon runs the same as it would in a linux VM. I keep the IaC faith and don’t install any sort of git GUI.

I use GitHub to host repos.

Docker Daemon

  • I installed Docker Daemon directly on Ubuntu in WSL.

  • I do NOT recommend installing Docker Desktop for Windows, though it can be “passed through” to your WSL VM. It is helpful to do everything via Docker CLI to increase your DevOps skills and to simulate a production Linux VM.

  • Use these directions to Install Docker in WSL 2 without Docker Desktop I originally set up Docker for use with VSCode devcontainers and it was available for this project with no additional work.

  • The Jenkins docs has instructions for running Jenkins as a Docker Container

    • Because we’re running in WSL, we use the instructions to manage Docker as a non-root user in Linux. It links to Linux post-installation steps for Docker Engine.

    • TLDR:

      • After installing Docker, you will create a group called Docker, add your user to it, and hot load the group membership.
      sudo groupadd docker && sudo usermod -aG docker $USER && newgrp docker
      • Test by running docker run hello-world
      • You should also make Docker boot on WSL start with systemd.
      sudo systemctl enable docker.service
      sudo systemctl enable containerd.service

Step 0: Create A Git Repo for this project

We create many files for this project. I recommend that you create a git repo called docker-cicd.

I have a dev folder in my Linux home dir that I use for all my projects. I cd to ~/dev/ and pull down my repo, resulting in ~/dev/docker-cicd/.

The core containers for our CI/CD stack are Jenkins, DinD, and SonarQube. When we use the stack they all need to be running, otherwise they are stopped to save local machine resources.

Step 1: Create Jenkins Automation Code

Each container gets its own subdirectory. Jenkins gets ~/dev/docker-cicd/jenkins/.

The Plugin Installation Manager

We are automating the installation of all of our plugins using jenkins-plugin-cli.

These days, the app is built into Jenkins Docker images, so we don’t need to install it. We use it to bake all the plugins in to our custom Docker image with code.

The list below adds all default/recommended plugins, plus a few extra ones we need, including the JCasC (Configuration As Code Plugin). It also includes plugins that we use later in this series to create a Docker “cloud” using DinD, and to integrate with SonarQube.

The format is “shortname:version”. If no version is specified, it pulls the latest version.

See “Addendum: How To Output A List of your Installed Jenkins Plugins” below to learn how to get a list of installed plugins in an existing Jenkins server. Its how I generated the plugins.txt list below.

  • Create an empty plugins.txt in ~/dev/docker-cicd/jenkins/.
  • Copy and past the text below into plugins.txt.
# plugins.txt

ant
antisamy-markup-formatter
apache-httpcomponents-client-4-api
authentication-tokens
blueocean
blueocean-bitbucket-pipeline
blueocean-commons
blueocean-config
blueocean-core-js
blueocean-dashboard
blueocean-display-url
blueocean-events
blueocean-git-pipeline
blueocean-github-pipeline
blueocean-i18n
blueocean-jwt
blueocean-personalization
blueocean-pipeline-api-impl
blueocean-pipeline-editor
blueocean-pipeline-scm-api
blueocean-rest
blueocean-rest-impl
blueocean-web
bootstrap5-api
bouncycastle-api
branch-api
build-timeout
caffeine-api
checks-api
cloudbees-bitbucket-branch-source
cloudbees-folder
command-launcher
commons-lang3-api
commons-text-api
configuration-as-code
credentials
credentials-binding
display-url-api
docker-commons
docker-java-api
docker-plugin
docker-workflow
durable-task
echarts-api
email-ext
favorite
font-awesome-api
git
git-client
github
github-api
github-branch-source
gradle
handy-uri-templates-2-api
htmlpublisher
instance-identity
ionicons-api
jackson2-api
jakarta-activation-api
jakarta-mail-api
javax-activation-api
javax-mail-api
jaxb
jdk-tool
jenkins-design-language
jjwt-api
jquery3-api
junit
ldap
mailer
matrix-auth
matrix-project
mina-sshd-api-common
mina-sshd-api-core
okhttp-api
pam-auth
pipeline-build-step
pipeline-github-lib
pipeline-graph-analysis
pipeline-groovy-lib
pipeline-input-step
pipeline-milestone-step
pipeline-model-api
pipeline-model-definition
pipeline-model-extensions
pipeline-rest-api
pipeline-stage-step
pipeline-stage-tags-metadata
pipeline-stage-view
plain-credentials
plugin-util-api
pubsub-light
quality-gates
resource-disposer
scm-api
script-security
snakeyaml-api
sonar
sonar-quality-gates
sse-gateway
ssh-credentials
ssh-slaves
sshd
structs
timestamper
token-macro
trilead-api
variant
workflow-aggregator
workflow-api
workflow-basic-steps
workflow-cps
workflow-durable-task-step
workflow-job
workflow-multibranch
workflow-scm-step
workflow-step-api
workflow-support
ws-cleanup

JCasC (Jenkins Configuration As Code)

We use the Configuration As Code Plugin to automate as much of the Jenkins setup routine as possible and we bake it into our custom Jenkins Docker image.

We set up a CasC folder for the config yaml files so we can break our configs into seperate files, based on config “roots”. The rule is that the config files cannot try to config the same settings or it will cause an error.

Addendum: Useful JCasC articles that I used to create this.

  • Create a subdirectory below the Dockerfile directory: ~/dev/docker-cicd/jenkins/casc_configs/
  • Create the files casc_configs/jenkins.yaml and casc_configs/unclassified.yaml.

Jenkins core is not a plugin, but we can config it in CasC. Examples are here. Jenkins is one of the config “roots” so, by convention, it gets its own yaml file.

# jenkins.yaml
jenkins:
  systemMessage: "EdPike365: Automating Jenkins Setup using Docker and Jenkins Configuration as Code\n\n"
  remotingSecurity:
   enabled: true
  securityRealm:
    local:
      allowsSignup: false
      users:
       - id: ${JENKINS_ADMIN_ID}
         password: ${JENKINS_ADMIN_PASSWORD}
       - id: edpike365
         name: "Ed Pike, Esquire"
         password: edpike365
         properties:
         - mailer:
             emailAddress: "you@you.com"
  authorizationStrategy:
    globalMatrix:
      permissions:
        - "Overall/Administer:${JENKINS_ADMIN_ID}"
        - "Overall/Read:authenticated"
        - "Job/Build:authenticated"
        - "Job/Cancel:authenticated"
        - "Job/Configure:authenticated"
        - "Job/Create:authenticated"
        - "Job/Delete:authenticated"
        - "Job/Discover:authenticated"
        - "Job/Move:authenticated"
        - "Job/Read:authenticated"
        - "Job/Workspace:authenticated"
        - "View/Read:anonymous"

Whats happening here?

  • users:
    • We create a user to be the admin using the docker run args.
    • We create a non admin user edpike365. I added some example user configs there as well.
  • globalMatrix:
    • The matrix config gives the admin full power with the line - "Overall/Administer:${JENKINS_ADMIN_ID}", which takes our docker run arg by the same name and reuses it here.
    • Other authenticated users can only do job stuff.

“Unclassified” is another config root and gets its own file.

# unclassified.yaml
unclassified:
  location:
    adminAddress: you@example.com
    url: http://localhost:8080

Step 2: Custom Jenkins Docker Image

Custom Jenkins Dockerfile

# Dockerfile
# Jenkins LTS as of 2023-05-03
FROM jenkins/jenkins:2.387.3

USER root

# Update and install modules, show Linux Standard Base info
RUN apt-get update && apt-get install -y lsb-release

# Setup access to docker hub
RUN curl -fsSLo /usr/share/keyrings/docker-archive-keyring.asc \
  https://download.docker.com/linux/debian/gpg
RUN echo "deb [arch=$(dpkg --print-architecture) \
  signed-by=/usr/share/keyrings/docker-archive-keyring.asc] \
  https://download.docker.com/linux/debian \
  $(lsb_release -cs) stable" > /etc/apt/sources.list.d/docker.list

# Install the Docker community edition CLI
# Our docker run code specifies DOCKER_HOST so local Docker commands are executed on a remote Docker daemon
RUN apt-get update && apt-get install -y docker-ce-cli

USER jenkins

ENV JAVA_OPTS -Djenkins.install.runSetupWizard=false

COPY ./casc_configs /var/jenkins_home/casc_configs
ENV CASC_JENKINS_CONFIG /var/jenkins_home/casc_configs

COPY plugins.txt /usr/share/jenkins/ref/plugins.txt
RUN jenkins-plugin-cli --plugin-file /usr/share/jenkins/ref/plugins.txt

Whats happening here?

  • install Docker hub credentials to the keyring
  • install Docker CE CLI
  • disable the setup wizard
  • copy our local casc_configs config folder to /var/jenkins_home/casc_configs on the image
  • copy our local plugins list file to /usr/share/jenkins/ref/plugins.txt on the image

Build The Custom Image

Build the image from within ~/dev/docker-cicd/jenkins/.

docker build -t jenkins:2.387.3-custom .

Explanation?

  • We add “-custom” to the name to clearly mark it as a custom image (I put it at the end of the image name so that a list of images will sort, with the default image listed above it).

Step 3: Custom Jenkins Container

Create a bridge network

This is so all of our containers can talk to each other easily later. This will become useful in Part 2 of this Series (DinD). We set it up now so we can add the Jenkins container to it and not have to edit our Docker run code later.

docker network create jenkins

Create Docker run bash script

Create a file named jenkins/docker-run-jenkins.sh and paste the code below into it. Modify to taste.

docker run --name jenkins \
  --detach \
  --restart unless-stopped \
  --network jenkins \
  --env DOCKER_HOST=tcp://docker:2375 \
  --env DOCKER_CERT_PATH="" \
  --env DOCKER_TLS_VERIFY="" \
  --publish 8080:8080 \
  --publish 50000:50000 \
  --env JENKINS_ADMIN_ID=myadmin --env JENKINS_ADMIN_PASSWORD=myadmin \
  --volume jenkins-data:/var/jenkins_home \
  --volume jenkins-docker-certs:/certs/client:ro \
  jenkins:2.387.3-custom

Settings explained:

  • –restart unless-stopped: If you explicitly shut down Jenkins, it will not restart automatically. You will have to docker start it.
  • We use the jenkins network created above.
  • This stack is meant to run completely on your local machine. Therefore, we will not enable docker TLS.
    • –env DOCKER_HOST=tcp://docker:2375 (instead of 2376)
    • –env DOCKER_CERT_PATH="" (instead of /certs/client)
    • –env DOCKER_TLS_VERIFY="" (instead of 1)
  • Our JCasC setup (above section) requires that we pass in the JENKINS_ADMIN_ID and JENKINS_ADMIN_PASSWORD.

Type bash docker-run-jenkins.sh

Log in to Jenkins at http://localhost:8080. It should be ready to go!

  • Log in as the admin we created dynamically in JCasC from the Docker env vars:

    • user: “myadmin”, password: “myadmin”
    • Everything should be available in the GUI, including Jenkins mgt.
  • Logout, then login as the hardcoded, non-admin user from JCasC:

    • user: “edpike365”, password: “edpike365”
    • You should not see any Jenkins admin options

Don’t forget that you can access the Jenkins container via docker exec -it jenkins bash

If Jenkins Doesn’t Work

I made these useful bash scripts while developing this tutorial.

clean-jenkins.sh: deletes the old Jenkins and its volumes

#!/bin/bash
# clean-jenkins.sh
CONTAINERID=$(docker ps -aqf "name=jenkins")
if [[ ! -z "$CONTAINERID" ]]
then
  echo "Container named jenkins existed."
  echo "CONTAINERID is $CONTAINERID"
  docker stop $CONTAINERID
  docker rm $CONTAINERID
  echo "Jenkins container stopped and removed."
else
  echo "CONTAINERID was empty, container named jenkins did not exist."
fi
docker volume rm jenkins-data
docker volume rm jenkins-docker-certs
echo "Jenkins volumes removed."

reset-jenkins.sh runs clean-jenkins.sh, builds the image and runs docker-run-jenkins.sh.

#!/bin/bash
# reset-jenkins.sh
bash ./clean-jenkins.sh
docker build -t jenkins:2.387.3-custom .
bash ./docker-run-jenkins.sh

Step 4: Tests

Test 1: Local Hello World Pipeline

Use the built in “Hello World” pipeline to test for basic functionality.

  • Jenkins Dashboard > New Item > Item Name “hello test” > Choose Pipeline > OK
  • Scroll down to the Pipeline Script area.
  • In the upper right corner, use the “try sample Pipeline” dropdown to select “Hello World”.
  • Save > Build Now
  • After it completes, it should have a green block in “Stage View”.
  • To view the details, click on “Build History” > #1 (in lower left corner)

Test 2: Jenkinsfile Pipeline to Public Github Repo

2.1: Prepare a Public Repo

The repo needs at least one branch with a Jenkinsfile in the root directory.

  • Option 1: Use one of your existing public repos

  • Option 2: Create a simple public repo:

    • In GitHub (any SCM), create a public repo. I called mine jenkins-docker-public-test.
    • Set as public. Leave all other values default. “Create Repository”.
    • Choose “Quick Setup” and click the little “Get started by creating a new file” link.
    • Using the web GUI, create a Jenkinsfile in project root. Paste in the “Hello World” content bellow.
      • I use main as the default branch name; yours might be master
    • Click the “Commit changes” button.
pipeline {
    agent any

    stages {
        stage('Hello') {
            steps {
                echo 'Hello World from PUBLIC repo MAIN branch.'
            }
        }
    }
}

2.2: Run a Pipeline

In Jenkins:

  • click “New Item”
  • “Item Name”: jenkins-docker-public-test (arbitrary but useful name)
  • click “Pipeline”
  • click “OK”
  • leave everything blank until the Pipeline section:
    • set Definition dropdown to “Pipeline script from SCM”
    • “SCM”: Git
    • follow the directions below to get the Repo URL

In GitHub:

  • click the <> Code button in the upper left corner

  • then click the other <> Code button in the somewhat upper right

  • select HTTPS and click the copy icon to get the link

  • paste it into the “Repository URL” field

  • leave Credentials as “-none-”

  • change Branches to build to match your main (and likely only branch). I had to change mine from ”/master” to ”/main”

  • click Save, then click “Build Now”. It should complete and show 2 stages in green:

    • “Declarative Checkout SCM”
    • “Hello”
  • click on “Build History” job link

  • click on “Console Output” and scan it

    • it should end in “Finished: SUCCESS”

Test 3: Jenkinsfile Pipeline to Private Repo With JCasC Credentials

Boss Fight!

3.1: JCasC Credential Code

We are creating a Jenkins “usernamePassword” type credential, though technically the password is a PAT (Personal Access Token). We’re using a PAT because password auth was removed in 2021. But we do it with JCasC.

The code below looks for SCM_TOKEN and SCM_USERNAME to be passed in. We don’t want to hard code those anywhere that Git might git them.

  • “Credentials” are a JCasC root config object, so it could, and should, get its own file.
  • Add a credentials.yaml file to your casc_configs directory. Paste this content:
credentials:
  system:
    domainCredentials:
      - credentials:
          - usernamePassword:
              id: "github-credentials"
              password: ${SCM_TOKEN}
              scope: GLOBAL
              username: ${SCM_USERNAME}

If you want to know more, sample JCasC credential configurations can be found at jenkins_credentials.yaml.

3.2: Modify Jenkins Docker Run Code

We pass in Host based ENV VARS to the docker-run-jenkins.sh, which in turn passes them to the JCasC code above.

Add the following lines to docker-run-jenkins.sh, under the existing JENKINS_ADMIN_ID line:

  --env SCM_USERNAME=$HOST_SCM_USERNAME \
  --env SCM_TOKEN=$HOST_SCM_TOKEN \

3.3: Create GitHub Personal Access Token

This video from CloudBeesTV is helpful if you don’t know how. It will also show you the traditional way to create credentials in Jenkins (vs using JCasC).

TLDR:

  • On GitHub:

    • click on your icon in the top right corner to produce a dropdown
    • select “Settings” > Developer Settings (bottom left) > Personal access tokens > Tokens (classic) > Generate new token > Generate new token (classic) (sic)
    • use “Note” as a name field
      • I named mine jenkins-docker-private-token
      • “Select scopes” Checkboxes:
        • “repo”
        • “user > user:email”
        • “admin:org > read:org”
      • Click “Generate token” button
      • Copy the PAT token using the copy icon. You won’t have access to it again!
  • On the Jenkins Linux Host:

    • Choose how to persist the env vars:
      • Permanent (recommended)

        • Choose where to persist the env vars. In Linux there are many options. How to permanently set environmental variables. Your choice affects how many users can see the variables so its a very important choice in a production environment. Also, make sure the credentials don’t get picked up by Git.
        • I added the below export lines to /etc/profile.d/docker-cicd.sh
          • Don’t forget sudo as in sudo vim /etc/profile.d/docker-cicd.sh
        export HOST_SCM_USERNAME=<your SCM user name>
        export HOST_SCM_TOKEN=<your SCM token>
        • Then I ran source /etc/profile.d/docker-cicd.sh to load them so I did not have to re-login to my Host.
      • Temporary (won’t persist on next boot):

        • This is problematic because if you want to use this next day, you’ll have to create a new GitHub token, etc.
        • OTOH your experiments are cleaned up when you shut down the VM.
        • Use your GitHub id and the PAT token to run the script above exporst on your Host bash prompt.

    In either approach, run the `reset-jenkins.sh` script.

3.4: Verify Credentials Exist in Jenkins

  • Log in as “myadmin”.
  • Navigate to Dashboard > Manage Jenkins > Scroll to “Credentials”.
  • You should see a system Credential there with ID as “github-credentials”.

3.5: Prepare a Private Multi Branch Repo

Create, or use an existing, private repo. It needs two branches. Each branch needs a Jenkinsfile.

I’m creating a private repo just for this tutorial:

  • In GitHub (or any cloud SCM), create a private repo.
  • I named mine jenkins-docker-private-test.
  • On themain branch, create a Jenkinsfile. Paste in the “Hello World” content.
pipeline {
    agent any

    stages {
        stage('Hello') {
            steps {
                echo 'Hello World from PRIVATE repo MAIN branch.'
            }
        }
    }
}
  • Create a feature branch. Edit the Jenkinsfile to say “FEATURE branch” at the end.

3.6: Use the Credentials to Run a Pipeline

We test our credentials with our private multi branch repo.

Create an MB Multibranch Pipeline job:

  • Dashboard > New Item

    • “Item Name”: jenkins-docker-private-test (arbitrary but useful name)
    • Choose Multibranch Pipleline
    • OK
  • General

    • Display Name: jenkins-docker-private-test (arbitrary)
    • Branch Sources > Add Source
      • GitHub
    • Credentials Dropdown
      • “github-credentials” will be listed as the “username/****”
    • Repo HTTPS URL > Get the HTTPS link to your test repo
    • Click “Validate” button
    • Behaviors > Discover branches > Strategy > All branches
    • Everything else leave as defaults
    • Save
    • The log should show that both branches had a Jenkinsfile.
  • Click on the job (for convenience, use the Dashboard > jenkins-docker-private-test breadcrumb in the upper left corner)

  • You will see 2 branchs listed by name. Each represents a normal pipeline

  • Click on one, view the Build History > Console Output and see the “Hello World” message.

FINALLY: After the tests pass, make and test our our IaC script

Create Stack IaC Scripts

They will to control our local devops stack. For now its just Jenkins, but it will grow in later parts of this series.

Stack Status

#!/bin/bash
# ~/dev/docker-cicd/status-stack.sh

# jenkins network
JENKINS_NETWORK=$(docker network inspect jenkins 2>&1)
if [ "$?" -eq 0 ];
then
  echo "Jenkins network exists."
else
  echo "Jenkins network DOES NOT exist!"
fi

# jenkins container
CONTAINERID=$(docker container inspect jenkins 2>&1)
if [ "$?" -eq 0 ];
then
  echo "Jenkins container exists."
else
  echo "Jenkins container DOES NOT exist!"
fi

# jenkins folders
JENKINS_DATA=$(docker volume inspect jenkins-data 2>&1)
if [ "$?" -eq 0 ];
then
  echo "Volume jenkins-data exists."
else
  echo "Volume jenkins-data DOES NOT exist!"
fi

JENKINS_DOCKER_CERTS=$(docker volume inspect jenkins-docker-certs 2>&1)
if [ "$?" -eq 0 ];
then
  echo "Volume jenkins-docker-certs exists."
else
  echo "Volume jenkins-docker-certs DOCES NOT exist!"
fi

# SCM tokens host env vars
if [[ ! -z "$HOST_SCM_USERNAME" ]]
then
  echo "Host SCM username exists."
else
  echo "Host SCM username was EMPTY!"
fi

if [[ ! -z "$HOST_SCM_TOKEN" ]]
then
  echo "Host SCM token exists."
else
  echo "Host SCM token was EMPTY!"
fi

Build Stack Images

Create the stack. Assumes Dockerfiles are in the subfolders.

#!/bin/bash
# ~/dev/docker-cicd/build-stack.sh
docker build . -t jenkins:2.387.3-custom -f ./jenkins/Dockerfile

Run Stack Containers

Startup scripts to create the jenkins network and run each container.

#!/bin/bash
# ~/dev/docker-cicd/run-stack.sh
bash ./jenkins/docker-run-jenkins.sh

Stop Stack Containers

Stop, but don’t delete all the containers.

#!/bin/bash
# ~/dev/docker-cicd/stop-stack.sh
docker stop jenkins

Remove Stack Containers and Network

Runs stop-stack.sh then removes all containers and the Jenkins network.

#!/bin/bash
# ~/dev/docker-cicd/remove-stack.sh

sh ./stop-stack.sh
docker container rm jenkins

docker network rm jenkins

Clean Stack (complete reset)

Runs remove-stack.sh, which runs stop-stack.sh, and then removes volumes. Leaves the images in place.

#!/bin/bash
# ~/dev/docker-cicd/clean-stack.sh
sh ./stop-stack.sh
sh ./clean-stack.sh
sh ./jenkins/clean-jenkins.sh

Test persistance:

stop-stack.sh

delete-stack.sh:

  • verify with docker ps -a

  • run (and create) the container: docker-run-jenkins.sh

  • log in to Jenkins, check the following exist:

    • GitHub credentials (could just be from JCasC)
    • build jobs

Edit `~/dev/docker-cicd/launch-stack.sh` to add our Jenkins container.
#!/bin/bash
bash ./jenkins/docker-run-jenkins.sh

Addendums

Addendum: Useful JCasC Articles

Addendum: How To Output And Use A List of Your Installed Jenkins Plugins

We are using Plugin Installation Manager Tool for Jenkins. It replaces install-plugins.sh from ye olden days.

We can specify a --plugin-file /path/to/file and also --plugins "space delimited list of plugins"

The expected formats for plugins in the plugins.txt file, or entered in the --plugins "space delimited list of plugins" option, are:

  • artifact ID:version (if no version specified, latest is used)
  • artifact ID:url
  • artifact:version:url

Run this script to display list of current plugins in jenkins/script interface. The results are in two formats:

  • A summary that gives you the most useful info.
  • An abbreviated version that will get the latest of each plugin that we can use for plugins.txt.

Edit the second list if you want to use one of the other formats for the Plugin Tool.

To run the script go to http://localhost:8080/script, or go to Dashboard > Manage Jenkins > Script Console.

def pluginList = new ArrayList(Jenkins.instance.pluginManager.plugins)

//List them with full info
println ("Format: DisplayName ShortName: Version: URL")
println ("=======================================")
pluginList.sort { it.getShortName() }.each{
  plugin ->
    println ("${plugin.getDisplayName()} (${plugin.getShortName()}): ${plugin.getVersion()}: ${plugin.getUrl()}")
}

println()
println()

//List them in a version that will fetch the latest, if thats what you are in to.
println ("Format: DisplayName")
println ("=======================================")
pluginList.sort { it.getShortName() }.each{
  plugin ->
    println ("${plugin.getShortName()}")
}

//If these are not here, the function appends some useless text here.
println()
println()
Subscribe To My Newsletter


Profile picture
By Ed Pike
Full Stack, DevOps, Tech Educator, Science Enthusiast.
